產品規(guī)格
All of the flowmeter regulators have easily accessible flow adjustment knobs to provide hospitals with precise control of multiple gas sources.
If you want to know more about our medical regulator, please call us at + 8618616308208 or send enquiry to sales@yufengmed.com.
Piston type
Gas Type: Oxygen, Medical Air
Flow range: 0-5, 0-10, 0-15LPM
Chromed forged brass body for endurable and compact
Backpressure compensated flowmeters
3000 psi maximum inlet pressure
Easy to read flow rate window
Accessories: humidifier bottle, cannula
Connecting thread: G 5/8, CGA540, G 5/8, G3 / 4, DIN477, and CGA870.
1.Connecting thread:CGA540 or BULL NOSE or CGA870
2.Integrated casting flowmeter
3.Polymer high-density filter,wet-based uniform
4.Outlet pressure:0.2-0.3Mpa
5.Inlet pressure:15Mpa
6.Material:Chromed Brass
7.Flow rate:1-15L/min
8.Control Pressure Safety Valve:3.5± 0.5 Bar
9.Humidifier Capacity:200ml and high quality Polycarbonate bottle autoclave 121℃
10.Easy to read dual scal gauge with screw-on polycarbonate lens for durability.
